BR2551e-u1
|
Bluetooth® Version |
Bluetooth® v5.2 BR/EDR + Low Energy compliant, Class 1 |
|
Profiles |
SPP, HID, ATT, GATT, HOGP, iAP2 |
|
Size(LxWxH, mm) |
15x12x2.5(Tolerance: ±0.2mm) |
|
Operation Temperature |
-40˚C to +85˚C |
|
Operation Voltage |
3.3V(1.8 ~ 3.6V) |
|
Communication distance |
50m(open air) |
|
Antenna |
Bulit-in antenna |
|
RX Sensitivity |
-94dBm(LE)@1Mbps
-92dBm(BR/EDR) |
|
TX Power |
up to 6dBm |
|
Power consumption |
RX(SPP): 6.83mA
TX(SPP): 5.68mA RX(GATT): 6.8mA TX(GATT): 5.71mA Idle: 2mA |
|
Memory |
96K RAM, 384KB ROM, 512KB Flash |
|
Interfaces |
DMA(1x8 channels), UART(2), SPI, I2C, GPIO(16), USB |
|
Certificates |
Bluetooth, CE, TELEC, KC, SRRC |
